This article provides the creation and the demonstration of the Bing Image API on the Azure Portal using the Bing Search API in the Microsoft Azure. The Bing Image Search API provides an experience similar to Google.com/Images by allowing you to send a query to Bing and the result will produce the relevant images for the query.
Prerequisites
  • An Azure Account.
Let's start to create the Bing Image Search on The Azure Portal:
Step-1
Sign-in into the Azure Portal.
Step-2
In the Portal, Press "+New" then "AI+Cognitive Services" and followed by "Bing Search API."

Step-3
In the Create Blade, Enter the name for our API and choose the desired subscription for our API and then choose the desired pricing tier and click "Select."



Step-4
Then create a new resource group for our API and then accept the conditions for the data monitoring on our API and then press "Create."



Step-5
After the successful creation of our API then it opens the properties of our API and press "Keys" to get our keys.



Step-6
It open Manage keys blade, press the copy button and paste it in our clipboard.


Step-7
Here we are going to create the single webpage app, then we are using the keys on the webpage to perform the Image search operation.copy and paste the code into your notepad and save the document as HTML.
  1. <!DOCTYPE html>
  2. <!-- saved from url=(0014)about:internet -->
  3. <!-- the above Mark of the Web lets IE run this page in the Internet security zone,
  4. avoiding the permission prompt for running active content such as JavaScript -->
  5. <html>
  6. <head>
  7. <meta charset="UTF-8">
  8. <title>Bing Image Search API Demo</title>
  9. <base target="_blank">
  10. <style type="text/css">
  11. html, body, div, p, h1, h2 {font-family: Verdana, "Lucida Sans", sans-serif; color: #000;}
  12. html, body, div, p {font-weight: normal;}
  13. body {background-color: #fff;}
  14. h1, h2, h3 {font-weight: bold; color: #087;}
  15. sup {font-weight: normal;}
  16. html, body, div, p {font-size: 12px;}
  17. h1 {font-size: 20px; margin-top: 30px;}
  18. h2 {font-size: 16px; clear: left;}
  19. h3 {font-size: 14px; clear: left;}
  20. #sidebar {font-size: 10px; text-align: right; display: flex; padding: 0px 10px;
  21. float: right; margin-left: 15px; margin-right: 0px;}
  22. #sidebar p {margin-top: 0px; font-size: 10px;}
  23. #sidebar img {display: inline-block; float: none; padding-right: 0px;}
  24. #pole p {font-size: 14px;}
  25. #pole, #mainline, #json, #http, #sidebar, #error, #paging1, #paging2
  26. {display: none;}
  27. #term {width: 100%;}
  28. #logo {padding: 15px; float: right; border-left: 2px solid #ccc;}
  29. #query {float: left;}
  30. img {vertical-align: top; float: left; margin-right: 10px; margin-bottom: 10px;}
  31. p.images {display: inline-block; font-size: 9px; vertical-align: top;}
  32. p.images img {float: none;}
  33. p.relatedSearches {clear: none;}
  34. #logo p, p.news, p.webPages, p.images {clear: left;}
  35. a[href="#"]:link {color: blue;}
  36. a[href="#"]:visited {color: blue;}
  37. h3 a:visited {color: #087 !important;}
  38. h3 a:link {color: #087 !important;}
  39. </style>
  40. <script type="text/javascript">
  41. // cookie names for data we store
  42. // YOUR API KEY DOES NOT GO IN THIS CODE; don't paste it in.
  43. API_KEY_COOKIE = "bing-search-api-key";
  44. CLIENT_ID_COOKIE = "bing-search-client-id";
  45. // Bing Search API endpoint
  46. BING_ENDPOINT = "https://api.cognitive.microsoft.com/bing/v7.0/images/search";
  47. // Various browsers differ in their support for persistent storage by local
  48. // HTML files (IE won't use localStorage, but Chrome won't use cookies). So
  49. // use localStorage if we can, otherwise use cookies.
  50. try {
  51. localStorage.getItem; // try localStorage
  52. window.retrieveValue = function (name) {
  53. return localStorage.getItem(name) || "";
  54. }
  55. window.storeValue = function(name, value) {
  56. localStorage.setItem(name, value);
  57. }
  58. } catch (e) {
  59. window.retrieveValue = function (name) {
  60. var cookies = document.cookie.split(";");
  61. for (var i = 0; i < cookies.length; i++) {
  62. var keyvalue = cookies[i].split("=");
  63. if (keyvalue[0].trim() === name) return keyvalue[1];
  64. }
  65. return "";
  66. }
  67. window.storeValue = function (name, value) {
  68. var expiry = new Date();
  69. expiry.setFullYear(expiry.getFullYear() + 1);
  70. document.cookie = name + "=" + value.trim() + "; expires=" + expiry.toUTCString();
  71. }
  72. }
  73. // get stored API subscription key, or prompt if it's not found
  74. function getSubscriptionKey() {
  75. var key = retrieveValue(API_KEY_COOKIE);
  76. while (key.length !== 32) {
  77. key = prompt("Enter Bing Search API subscription key:", "").trim();
  78. }
  79. // always set the cookie in order to update the expiration date
  80. storeValue(API_KEY_COOKIE, key);
  81. return key;
  82. }
  83. // invalidate stored API subscription key so user will be prompted again
  84. function invalidateSubscriptionKey() {
  85. storeValue(API_KEY_COOKIE, "");
  86. }
  87. // escape text for use in HTML
  88. function escape(text) {
  89. return text.replace(/&/g, "&").replace(/</g, "<").
  90. replace(/'/g, "'").replace(/"/g, """);
  91. }
  92. // get the host portion of a URL, strpping out search result formatting and www too
  93. function getHost(url) {
  94. return url.replace(/<\/?b>/g, "").replace(/^https?:\/\//, "").split("/")[0].replace(/^www\./, "");
  95. }
  96. // format plain text for display as an HTML <pre> element
  97. function preFormat(text) {
  98. text = "" + text;
  99. return "<pre>" + text.replace(/&/g, "&").replace(/</g, "<") + "</pre>"
  100. }
  101. // put HTML markup into a <div> and reveal it
  102. function showDiv(id, html) {
  103. var content = document.getElementById("_" + id)
  104. if (content) content.innerHTML = html;
  105. var wrapper = document.getElementById(id);
  106. if (wrapper) wrapper.style.display = html.trim() ? "block" : "none";
  107. }
  108. // hides the specified <div>s
  109. function hideDivs() {
  110. for (var i = 0; i < arguments.length; i++) {
  111. var element = document.getElementById(arguments[i])
  112. if (element) element.style.display = "none";
  113. }
  114. }
  115. // render functions for various types of search results
  116. searchItemRenderers = {
  117. images: function (item, index, count) {
  118. var height = 120;
  119. var width = Math.max(Math.round(height * item.thumbnail.width / item.thumbnail.height), 120);
  120. var html = [];
  121. if (index === 0) html.push("<p class='images'>");
  122. var title = escape(item.name) + "\n" + getHost(item.hostPageDisplayUrl);
  123. html.push("<p class='images' style='max-width: " + width + "px'>");
  124. html.push("<img src='"+ item.thumbnailUrl + "&h=" + height + "&w=" + width +
  125. "' height=" + height + " width=" + width + "'>");
  126. html.push("<br>");
  127. html.push("<nobr><a href='" + item.contentUrl + "'>Image</a> - ");
  128. html.push("<a href='" + item.hostPageUrl + "'>Page</a></nobr><br>");
  129. html.push(title.replace("\n", " (").replace(/([a-z0-9])\.([a-z0-9])/g, "$1.<wbr>$2") + ")</p>");
  130. return html.join("");
  131. },
  132. relatedSearches: function(item) {
  133. var html = [];
  134. html.push("<p class='relatedSearches'>");
  135. html.push("<a href='#' onclick='return doRelatedSearch("" +
  136. escape(item.text) + "")'>");
  137. html.push(item.displayText + "</a>");
  138. return html.join("");
  139. }
  140. }
  141. // render image search results
  142. function renderImageResults(items) {
  143. var len = items.length;
  144. var html = [];
  145. if (!len) {
  146. showDiv("noresults", "No results.");
  147. hideDivs("paging1", "paging2");
  148. return "";
  149. }
  150. for (var i = 0; i < len; i++) {
  151. html.push(searchItemRenderers.images(items[i], i, len));
  152. }
  153. return html.join("\n\n");
  154. }
  155. // render related items
  156. function renderRelatedItems(items) {
  157. var len = items.length;
  158. var html = [];
  159. for (var i = 0; i < len; i++) {
  160. html.push(searchItemRenderers.relatedSearches(items[i], i, len));
  161. }
  162. return html.join("\n\n");
  163. }
  164. // render the search results given the parsed JSON response
  165. function renderSearchResults(results) {
  166. // add Prev / Next links with result count
  167. var pagingLinks = renderPagingLinks(results);
  168. showDiv("paging1", pagingLinks);
  169. showDiv("paging2", pagingLinks);
  170. showDiv("results", renderImageResults(results.value));
  171. if (results.relatedSearches)
  172. showDiv("sidebar", renderRelatedItems(results.relatedSearches));
  173. }
  174. function renderErrorMessage(message) {
  175. showDiv("error", preFormat(message));
  176. showDiv("noresults", "No results.");
  177. }
  178. // handle Bing search request results
  179. function handleBingResponse() {
  180. hideDivs("noresults");
  181. var json = this.responseText.trim();
  182. var jsobj = {};
  183. // try to parse JSON results
  184. try {
  185. if (json.length) jsobj = JSON.parse(json);
  186. } catch(e) {
  187. renderErrorMessage("Invalid JSON response");
  188. }
  189. // show raw JSON and HTTP request
  190. showDiv("json", preFormat(JSON.stringify(jsobj, null, 2)));
  191. showDiv("http", preFormat("GET " + this.responseURL + "\n\nStatus: " + this.status + " " +
  192. this.statusText + "\n" + this.getAllResponseHeaders()));
  193. // if HTTP response is 200 OK, try to render search results
  194. if (this.status === 200) {
  195. var clientid = this.getResponseHeader("X-MSEdge-ClientID");
  196. if (clientid) retrieveValue(CLIENT_ID_COOKIE, clientid);
  197. if (json.length) {
  198. if (jsobj._type === "Images") {
  199. if (jsobj.nextOffset) document.forms.bing.nextoffset.value = jsobj.nextOffset;
  200. renderSearchResults(jsobj);
  201. } else {
  202. renderErrorMessage("No search results in JSON response");
  203. }
  204. } else {
  205. renderErrorMessage("Empty response (are you sending too many requests too quickly?)");
  206. }
  207. }
  208. // Any other HTTP response is an error
  209. else {
  210. // 401 is unauthorized; force re-prompt for API key for next request
  211. if (this.status === 401) invalidateSubscriptionKey();
  212. // some error responses don't have a top-level errors object, so gin one up
  213. var errors = jsobj.errors || [jsobj];
  214. var errmsg = [];
  215. // display HTTP status code
  216. errmsg.push("HTTP Status " + this.status + " " + this.statusText + "\n");
  217. // add all fields from all error responses
  218. for (var i = 0; i < errors.length; i++) {
  219. if (i) errmsg.push("\n");
  220. for (var k in errors[i]) errmsg.push(k + ": " + errors[i][k]);
  221. }
  222. // also display Bing Trace ID if it isn't blocked by CORS
  223. var traceid = this.getResponseHeader("BingAPIs-TraceId");
  224. if (traceid) errmsg.push("\nTrace ID " + traceid);
  225. // and display the error message
  226. renderErrorMessage(errmsg.join("\n"));
  227. }
  228. }
  229. // perform a search given query, options string, and API key
  230. function bingImageSearch(query, options, key) {
  231. // scroll to top of window
  232. window.scrollTo(0, 0);
  233. if (!query.trim().length) return false; // empty query, do nothing
  234. showDiv("noresults", "Working. Please wait.");
  235. hideDivs("results", "related", "_json", "_http", "paging1", "paging2", "error");
  236. var request = new XMLHttpRequest();
  237. var queryurl = BING_ENDPOINT + "?q=" + encodeURIComponent(query) + "&" + options;
  238. // open the request
  239. try {
  240. request.open("GET", queryurl);
  241. }
  242. catch (e) {
  243. renderErrorMessage("Bad request (invalid URL)\n" + queryurl);
  244. return false;
  245. }
  246. // add request headers
  247. request.setRequestHeader("Ocp-Apim-Subscription-Key", key);
  248. request.setRequestHeader("Accept", "application/json");
  249. var clientid = retrieveValue(CLIENT_ID_COOKIE);
  250. if (clientid) request.setRequestHeader("X-MSEdge-ClientID", clientid);
  251. // event handler for successful response
  252. request.addEventListener("load", handleBingResponse);
  253. // event handler for erorrs
  254. request.addEventListener("error", function() {
  255. renderErrorMessage("Error completing request");
  256. });
  257. // event handler for aborted request
  258. request.addEventListener("abort", function() {
  259. renderErrorMessage("Request aborted");
  260. });
  261. // send the request
  262. request.send();
  263. return false;
  264. }
  265. // build query options from the HTML form
  266. function bingSearchOptions(form) {
  267. var options = [];
  268. options.push("mkt=" + form.where.value);
  269. options.push("SafeSearch=" + (form.safe.checked ? "strict" : "off"));
  270. if (form.when.value.length) options.push("freshness=" + form.when.value);
  271. var aspect = "all";
  272. for (var i = 0; i < form.aspect.length; i++) {
  273. if (form.aspect[i].checked) {
  274. aspect = form.aspect[i].value;
  275. break;
  276. }
  277. }
  278. options.push("aspect=" + aspect);
  279. if (form.color.value) options.push("color=" + form.color.value);
  280. options.push("count=" + form.count.value);
  281. options.push("offset=" + form.offset.value);
  282. return options.join("&");
  283. }
  284. // toggle display of a div (used by JSON/HTTP expandos)
  285. function toggleDisplay(id) {
  286. var element = document.getElementById(id);
  287. if (element) {
  288. var display = element.style.display;
  289. if (display === "none") {
  290. element.style.display = "block";
  291. window.scrollBy(0, 200);
  292. } else {
  293. element.style.display = "none";
  294. }
  295. }
  296. return false;
  297. }
  298. // perform a related search (used by related search links)
  299. function doRelatedSearch(query) {
  300. var bing = document.forms.bing;
  301. bing.query.value = query;
  302. return newBingImageSearch(bing);
  303. }
  304. // generate the HTML for paging links (prev/next)
  305. function renderPagingLinks(results) {
  306. var html = [];
  307. var bing = document.forms.bing;
  308. var offset = parseInt(bing.offset.value, 10);
  309. var count = parseInt(bing.count.value, 10);
  310. html.push("<p class='paging'><i>Results " + (offset + 1) + " to " + (offset + count));
  311. html.push(" of about " + results.totalEstimatedMatches + ".</i> ");
  312. html.push("<a href='#' onclick='return doPrevSearchPage()'>Prev</a> | ");
  313. html.push("<a href='#' onclick='return doNextSearchPage()'>Next</a>");
  314. return html.join("");
  315. }
  316. // go to the next page (used by next page link)
  317. function doNextSearchPage() {
  318. var bing = document.forms.bing;
  319. var query = bing.query.value;
  320. var offset = parseInt(bing.offset.value, 10);
  321. var stack = JSON.parse(bing.stack.value);
  322. stack.push(parseInt(bing.offset.value, 10));
  323. bing.stack.value = JSON.stringify(stack);
  324. bingbing.offset.value = bing.nextoffset.value;
  325. return bingImageSearch(query, bingSearchOptions(bing), getSubscriptionKey());
  326. }
  327. // go to the previous page (used by previous page link)
  328. function doPrevSearchPage() {
  329. var bing = document.forms.bing;
  330. var query = bing.query.value;
  331. var stack = JSON.parse(bing.stack.value);
  332. if (stack.length) {
  333. var offset = stack.pop();
  334. var count = parseInt(bing.count.value, 10);
  335. bing.stack.value = JSON.stringify(stack);
  336. bing.offset.value = offset;
  337. return bingImageSearch(query, bingSearchOptions(bing), getSubscriptionKey());
  338. }
  339. alert("You're already at the beginning!");
  340. return false;
  341. }
  342. function newBingImageSearch(form) {
  343. form.offset.value = "0";
  344. form.stack.value = "[]";
  345. return bingImageSearch(form.query.value, bingSearchOptions(form), getSubscriptionKey());
  346. }
  347. // --></script>
  348. </head>
  349. <body onload="document.forms.bing.query.focus();">
  350. <form name="bing" onsubmit="return newBingImageSearch(this)">
  351. <div id="logo"><!-- logo block including search market/language -->
  353. <I>api</I>
  354. <p><select name="where">
  355. <option value="es-AR">Argentina (Spanish)</option>
  356. <option value="en-AU">Australia (English)</option>
  357. <option value="de-AT">Austria (German)</option>
  358. <option value="nl-BE">Belgium (Dutch)</option>
  359. <option value="fr-BE">Belgium (French)</option>
  360. <option value="pt-BR">Brazil (Portuguese)</option>
  361. <option value="en-CA">Canada (English)</option>
  362. <option value="fr-CA">Canada (French)</option>
  363. <option value="es-CL">Chile (Spanish)</option>
  364. <option value="da-DK">Denmark (Danish)</option>
  365. <option value="fi-FI">Finland (Finnish)</option>
  366. <option value="fr-FR">France (French)</option>
  367. <option value="de-DE">Germany (German)</option>
  368. <option value="zh-HK">Hong Kong (Traditional Chinese)</option>
  369. <option value="en-IN">India (English)</option>
  370. <option value="en-ID">Indonesia (English)</option>
  371. <option value="it-IT">Italy (Italian)</option>
  372. <option value="ja-JP">Japan (Japanese)</option>
  373. <option value="ko-KR">Korea (Korean)</option>
  374. <option value="en-MY">Malaysia (English)</option>
  375. <option value="es-MX">Mexico (Spanish)</option>
  376. <option value="nl-NL">Netherlands (Dutch)</option>
  377. <option value="en-NZ">New Zealand (English)</option>
  378. <option value="no-NO">Norway (Norwegian)</option>
  379. <option value="zh-CN">People's Republic of China (Chinese)</option>
  380. <option value="pl-PL">Poland (Polish)</option>
  381. <option value="pt-PT">Portugal (Portuguese)</option>
  382. <option value="en-PH">Philippines (English)</option>
  383. <option value="ru-RU">Russia (Russian)</option>
  384. <option value="ar-SA">Saudi Arabia (Arabic)</option>
  385. <option value="en-ZA">South Africa (English)</option>
  386. <option value="es-ES">Spain (Spanish)</option>
  387. <option value="sv-SE">Sweden (Swedish)</option>
  388. <option value="fr-CH">Switzerland (French)</option>
  389. <option value="de-CH">Switzerland (German)</option>
  390. <option value="zh-TW">Taiwan (Traditional Chinese)</option>
  391. <option value="tr-TR">Turkey (Turkish)</option>
  392. <option value="en-GB">United Kingdom (English)</option>
  393. <option value="en-US" selected>United States (English)</option>
  394. <option value="es-US">United States (Spanish)</option>
  395. </select>
  396. <p>from Microsoft Cognitive Services
  397. </div>
  398. <div id="query"><!-- query controls including search field and options -->
  399. <h1>Bing Image Search API demo</h2>
  400. <input type="text" name="query" id="term" placeholder="Search for images" autocomplete=off>
  401. <p>Aspect
  402. <input type=radio name="aspect" id="any" value="all" checked>
  403. <label for="any">Any</label>
  404. <input type=radio name="aspect" id="square" value="square">
  405. <label for="square">Square</label>
  406. <input type=radio name="aspect" id="wide" value="wide">
  407. <label for="wide">Wide</label>
  408. <input type=radio name="aspect" id="tall" value="tall">
  409. <label for="tall">Tall</label>
  410. Color
  411. <select name="color">
  412. <option value="" selected>Any</option>
  413. <option value="coloronly">Only Color</option>
  414. <option value="monochrome">Black and White</option>
  415. <option value="black">Black</option>
  416. <option value="blue">Blue</option>
  417. <option value="black">Brown</option>
  418. <option value="gray">Gray</option>
  419. <option value="green">Green</option>
  420. <option value="orange">Orange</option>
  421. <option value="pink">Pink</option>
  422. <option value="purple">Purple</option>
  423. <option value="red">Red</option>
  424. <option value="teal">Teal</option>
  425. <option value="white">White</option>
  426. <option value="yellow">Yellow</option>
  427. </select>
  428. From
  429. <select name="when">
  430. <option value="" selected>All time</option>
  431. <option value="month">Past month</option>
  432. <option value="week">Past week</option>
  433. <option value="day">Last 24 hours</option>
  434. </select>
  435. <input type=checkbox id="safe" name="safe" value="on" checked><label for="safe">SafeSearch</label>
  436. <!-- these hidden fields control paging -->
  437. <input type=hidden name="count" value="25">
  438. <input type=hidden name="offset" value="0">
  439. <input type=hidden name="nextoffset" value="">
  440. <input type=hidden name="stack" value="[]">
  441. </form>
  442. </div>
  443. <div id="error">
  444. <h2>Error</h2>
  445. <div id="_error">
  446. </div>
  447. </div>
  448. <h2>Results</h2>
  449. <div id="paging1">
  450. <div id="_paging1"></div>
  451. </div>
  452. <div id="noresults">
  453. <div id="_noresults">None yet.</div>
  454. </div>
  455. <div id="sidebar">
  456. <div id="_sidebar"></div>
  457. </div>
  458. <div id="results">
  459. <div id="_results"></div>
  460. </div>
  461. <div id="paging2">
  462. <div id="_paging2"></div>
  463. </div>
  464. <div id="json">
  465. <h3><a href="#" onclick="return toggleDisplay('_json')">JSON</a></h3>
  466. <div id="_json" style="display: none"></div>
  467. </div>
  468. <div id="http">
  469. <h3><a href="#" onclick="return toggleDisplay('_http')">HTTP</a></h3>
  470. <div id="_http" style="display: none"></div>
  471. </div>
  472. </body>
  473. </html>
On the 53rd and 54th line of our code, paste the Keys and then open the web page.
Step-8
On the web page, In the search bar, enter the query and it shows the result as per the query.

Summary
I hope you understood how to create the Bing Image search API and the Demonstration of the API.
